BuildPro Alpha 28 Cast Iron Clamping Squares, for 28mm Holes

Non Stock Item – Please allow a 2 week lead time on this product

Cast Angle Squares are manufactured from high-quality ductile cast iron. Their larger size and more robust construction allow them to stop larger parts and bear heavier loads when used as a table extension.

Available Options and Part Numbers



Part No.		Name		Length (mm)		Width (mm)		Height (mm)		Thickness (mm)		Weight (kg)
T28-23283		Cast Angle Square 275 – L		175		50		275		25		6.0
T28-23506L		HD Square 500, L		276		95		500		approx. 27		13.8
T28-23506R		HD Square 500, R		276		95		500		approx. 27		13.8
T28-23756L		HD Square 750, L		276		85		750		approx. 27		12.7
T28-23756R		HD Square 750, R		276		85		750		approx. 27		12.7

Model	T28-23283 – Cast Angle Square 275 – L, T28-23506L – HD Square 500, Left, T28-23506R – HD Square 500, Right, T28-23756L – HD Square 750, Left, T28-23756R – HD Square 750, Right
