Soudotec 75 Aluminum Brazing Rod



Bare rod made up of a high-strength and highly-liquefied aluminum alloy for brazing thin sheet, forged and cast aluminum alloys.

Characteristics

• Specially designed for dirty or difficult-to-weld aluminum alloys
• Very high fluidity
• Low bonding temperature
• Can be used with a torch or TIG process
• High mechanical resistance
• Excellent electrical conductivity
• Good color match on aluminum

• Typical Applications

  Pipes, refrigeration, body work (‘’hot roads‘’), radio instruments, aluminum furniture and boats, frames, etc.

  Procedure for Use

  Clean the brazing area and remove grease and dirt. Dip the hot end of the rod into Soudotec F075 flux and coat the joint surface with flux. Heat uniformly using a low carburizing flame. When the flux is fluid, heat the alloy on the joint until it penetrates. Wash out the flux residues with warm water.

  Mechanical Properties

  • Tensile strength:  34 000 psi  (235 MPa)

  • Available Diameters and Package Sizes

    • 3 32 (2.4 mm) – 1 Kg
