Victor EDGE ETS4-200-540 High Capacity Two Stage Oxygen Regulator Online
28 people are viewing this right now
2 products sold in last 8 hours
Selling fast! Over 11 people have this in their carts
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Victor EDGE ETS4-200-540 High Capacity Two Stage Oxygen Regulator
Â
The Victor ETS4 EDGE Series Two-Stage High-Capacity Oxygen Regulator (Model ETS4-200-540) is engineered for applications that require precise and consistent outlet pressure, even as inlet pressure decreases. Its advanced design combines robust construction, enhanced safety features, and user-friendly functionality, making it the ideal choice for professional and industrial use.
Key Features
-
SLAM Knob Design: Absorbs impact energy to safeguard critical components in the event of a cylinder fall.
-
-
Dual-Stage Regulation: Ensures superior delivery pressure consistency over a wide range of cylinder pressures.
-
-
Durable Build:
- Forged brass body for strength and durability.
-
- Zinc-aluminum housing caps and high-impact ABS gauge guard for added protection.
-
-
-
High Sensitivity & Accuracy: Provides uniform flow performance and precise delivery pressure.
-
-
User-Friendly Design:
- Easy-to-read gauges with enhanced graphics.
-
- Color-coded knobs for quick gas identification.
-
- Side-mounted adjustment knob for natural, safe hand positioning.
-
-
-
Advanced Safety:
- Single-impact point design for element protection.
-
- External self-reseating relief valve for added safety.
-
-
-
Long-Lasting Components: Includes sintered inlet filter (nickel-plated bronze), stainless steel diaphragm, and die-forged brass spring housing cap.
-
Specifications
-
Series: ETS4
-
-
Division: High-Capacity, Two-Stage
-
-
Gas Compatibility: Oxygen
-
-
Delivery Range: 10–200 PSIG
-
-
Max Inlet Pressure: 3000 PSIG
-
-
CGA Inlet Connection: 540
-
-
CGA Outlet Connection: 9 16 – 18 UNF (RH Male)
-
-
Gauges:
- Inlet Gauge Range: 0–4000 PSIG
-
- Outlet Gauge Range: 0–400 PSIG
-
- Size: 1.5 UL Listed Recognized
-
-
-
Diaphragm: 2.7 fabric-reinforced neoprene (second stage).
-
-
Dimensions: 6.85 x 4.72 x 4.4
-
-
Flow Coefficient (Cv): 0.488
-
-
Compliance: Meets or exceeds CGA E-4, UL 252, and ASTM G-175 ignition tests.
-
- Part No. 0781-5219
-
-
SLAM Knob Design: Absorbs impact energy to safeguard critical components in the event of a cylinder fall.
- Dual-Stage Regulation: Ensures superior delivery pressure consistency over a wide range of cylinder pressures.
- Durable Build:
- Forged brass body for strength and durability.
- Zinc-aluminum housing caps and high-impact ABS gauge guard for added protection.
-
-
High Sensitivity & Accuracy: Provides uniform flow performance and precise delivery pressure.
- User-Friendly Design:
- Easy-to-read gauges with enhanced graphics.
- Color-coded knobs for quick gas identification.
- Side-mounted adjustment knob for natural, safe hand positioning.
-
-
Advanced Safety:
- Single-impact point design for element protection.
- External self-reseating relief valve for added safety.
-
-
Long-Lasting Components: Includes sintered inlet filter (nickel-plated bronze), stainless steel diaphragm, and die-forged brass spring housing cap.
-
Series: ETS4
- Division: High-Capacity, Two-Stage
- Gas Compatibility: Oxygen
- Delivery Range: 10–200 PSIG
- Max Inlet Pressure: 3000 PSIG
- CGA Inlet Connection: 540
- CGA Outlet Connection: 9 16 – 18 UNF (RH Male)
- Gauges:
- Inlet Gauge Range: 0–4000 PSIG
- Outlet Gauge Range: 0–400 PSIG
- Size: 1.5 UL Listed Recognized
-
-
Diaphragm: 2.7 fabric-reinforced neoprene (second stage).
- Dimensions: 6.85 x 4.72 x 4.4
- Flow Coefficient (Cv): 0.488
- Compliance: Meets or exceeds CGA E-4, UL 252, and ASTM G-175 ignition tests.
- Part No. 0781-5219
