3M™ Speedglas™ G5-03 Welding Helmet



The 3M™ Speedglas™ G5-03 Pro Welding Helmet uses next-generation technology to help provide dynamic welding protection. Intuitively designed for the challenges faced on the job, this helmet setup includes a haptic tapping function to activate grind or cut mode. We make use of the welding technology of the future, today — equip the 3M™ Speedglas™ G5-03 Pro Welding Helmet with various accessories, such as task-light, neck Cover and head Cover to configure the helmet to meet your specific needs.

3M™ Speedglas™ Welding Helmet, G5-03 Pro is specifically designed for the versatile welder. The helmet allows you to switch between welding and grinding tasks through our new Tap functionality. With highly customisable adjustment settings, including more control over how you see your weld pool and how you configure the helmet for additional protection against radiation, sparks and spatter, G5-03 Pro allows you to take control over your protection. Features 3M™ Speedglas™ Natural Color Technology, Variable Color Technology (with G5-01 03VC), and a Tack Welding Mode (with G5-01 03TW). The new optional Task Light also allows you to see more of your work piece. an optional helmet adapter system also enables the connection of a hard hat for welders requiring head protection.

With the G5VC ADF, the welder can leverage variable color technology to view the weld while in dark state through either warm, cool, or natural color tones as different applications, lighting, and materials, may warrant different colors and contrasts.

With the G5TW ADF, there is a tack welding mode that uses an intermediate shade 5 light state to help minimize eye strain during tack welding applications. If an arc is not struck within 2 seconds, the welding filter will switch back to the normal light state of shade 2.5.

Lens Features

3M™ Speedglas™ Auto-darkening Welding Filter Series G5-01 03		G5-01 03VC		G5-01 03TW		G5-01 03NC*
MMAW (Stick Welding)
MIG MAG
TIG (>20A)
TIG (1A-20A)
Plasma (welding and cutting)
Tack welding
Grinding
Viewing area (welding filter)		109 x 73 mm		109 x 73 mm		107 x 55 mm
3M™ Speedglas™ Natural Colour Technology
Variable colour modes (A-B-C)
TAP function
Bluetooth enabled
Battery lifetime		1500–2000 hours		1500–2000 hours		2500 hours
Classification (ISO)		V2		V2		V2
Dark state		Shade 8–14		Shade 8–13		Shade 8–12
CUT mode		Shade 5		Shade 5		Shade 5
Tack welding mode
Light state		Shade 3		Shade 2.5		Shade 3
UV IR Protection		Shade 14 (permanent)		Shade 13 (permanent)		Shade 12 (permanent)
Auto ON
Switching time, light -dark		0.1 ms (+23° C)		0.1 ms (+23° C)		0.1 ms (+23° C)
Memory mode		Via mobile device app		Via mobile device app
Delay (switching time, dark-light)		50 – 1300 ms		50 – 1300 ms		40 – 470 ms
Number of sensors (arc detection)		4		4		3

Lens Option	G5VC Variable Colour Lens – 10-0100-30VC, G5TW Tack Weld Lens – 10-0100-30TW, No Auto Darkening Lens – 10-0100-00
