Bug-O MDS-1005 Weaver Control Module



Part of the modular drive system, the Weaver Control Module operates the Pendulum or Linear Weaver, and the Master Drive Unit.

Features Include:

• Digital readout and control knob for longitudinal travel speed
• Switch for Forward Stop Reverse tractor control
• Amplitude knob to set weave width from 1 8 -2 (3-50 mm)
• Weave speed control up to 100 in min (254 cm min)
• Controls for left and right dwell
• Knob to control steering up to 2 (50 mm), either side of center

• One of four weld patterns can be chosen using the mode selector switch, as shown in the figure below. The MDS-1005-DIAL Weaver Control Module w locking dials provides all of the function controls of the MDS-1005 and provides lockable numerical display dials for all oscillator functions.


  Part Number: MDS-1005
  Modular Drive System Brochure | All Bug-O Products
